TS 090 Unsealed Series

2-Way Kit
090IIU-2P-2
2-Way Kit
OEM P/N: 7282-1020
090IIU-2P-2  2-Way Kit
Kit Contents: Housing, 2 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7282-1020
Mating Part: 090IIU-2S-2

spacer
General
  • Sealing:Unsealed
  • Number of Ways:2
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10824
QtyPrice
1-5$2.17
6-19$2.06
20-49$1.95
50-99$1.84
100+$1.74
Quantity:  Kit

2-Way Kit
090IIU-2S-2
2-Way Kit
OEM P/N: 7283-6160 (ss: 7283-1020)
090IIU-2S-2  2-Way Kit
Kit Contents: Housing, 2 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7283-6160 (ss: 7283-1020)
Mating Part: 090IIU-2P-2, 7282-1022, 7282-8823, 7282-8824

spacer
General
  • Sealing:Unsealed
  • Number of Ways:2
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Mopar 68068634AA repair kit connector
  • Toyota 90980-10825, 90980-12014, 90980-12341, 90980-12471
QtyPrice
1-5$2.05
6-19$1.95
20-49$1.84
50-99$1.74
100+$1.64
Quantity:  Kit

2-Way Kit
090IIU-2S-6
2-Way Kit
OEM P/N: 7283-1026
090IIU-2S-6  2-Way Kit
Kit Contents: Housing, 2 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7283-1026
Mating Part: 7282-1026

spacer
General
  • Sealing:Unsealed
  • Number of Ways:2
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10935, 90980-11723, 90980-11770, 90980-12343, 90980-12347
  • Tokai Rika 4F5260-000
QtyPrice
1-5$2.60
6-19$2.47
20-49$2.34
50-99$2.21
100+$2.08
Quantity:  Kit

2-Way Kit
090IIU-2S-7
2-Way Kit
OEM P/N: 6240-5159 grey (in-stock)
6248-5342 natural
090IIU-2S-7  2-Way Kit
Kit Contents: Housing, 2 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-5159 grey (in-stock)
6248-5342 natural
Part Name: 11080N9A02F
Mating Part: N/A, device only

spacer
General
  • Sealing:Unsealed
  • Number of Ways:2
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:8.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-11080
QtyPrice
1-5$5.33
6-19$5.06
20-49$4.80
50-99$4.53
100+$4.26
Quantity:  Kit

3-Way Kit
090IIU-3P-1
3-Way Kit
OEM P/N: 6520-0492, 7282-1030
090IIU-3P-1  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6520-0492, 7282-1030
Part Name: 11763N9A03M-NA
Mating Part: 090IIU-3S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10907 (Yazaki), 90980-11763 (Sumitomo)
QtyPrice
1-5$2.55
6-19$2.42
20-49$2.29
50-99$2.17
100+$2.04
Quantity:  Kit

3-Way Kit
090IIU-3S-1
3-Way Kit
OEM P/N: 6520-0577, 7283-1030
090IIU-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6520-0577, 7283-1030
Part Name: 11764N9A03F-NA
Mating Part: 090IIU-3P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Mopar 68064999AA repair kit connector
  • Toyota 90980-10908, 90980-11764, 90980-12255, 90980-12473
QtyPrice
1-5$2.44
6-19$2.32
20-49$2.20
50-99$2.07
100+$1.95
Quantity:  Kit

5-Way Kit
NEW ITEM! 090IIU-5P-1
5-Way Kit
OEM P/N: 1300-3783, 7282-1050
NEW ITEM! 090IIU-5P-1  5-Way Kit
Kit Contents: Housing, 5 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 1300-3783, 7282-1050
Part Name: 11843N9A05M
Mating Part: 090IIU-5S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:5
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-11085, 90980-11719, 90980-11843
QtyPrice
1-5$3.58
6-19$3.40
20-49$3.22
50-99$3.04
100+$2.86
Quantity:  Kit

5-Way Kit
090IIU-5S-1
5-Way Kit
OEM P/N: 1300-3111 (Natural), 1300-3433 Black, 7183-6321
090IIU-5S-1  5-Way Kit
Kit Contents: Housing, 5 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 1300-3111 (Natural), 1300-3433 Black, 7183-6321
Part Name: 11772N9A05F-NA
Mating Part: 090IIU-5P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:5
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10789, 90980-11772, 90980-11797, 90980-12348
QtyPrice
1-5$3.20
6-19$3.04
20-49$2.88
50-99$2.72
100+$2.56
Quantity:  Kit

6-Way Kit
090IIU-6P-1
6-Way Kit
OEM P/N: 6240-1120, 7282-1060
090IIU-6P-1  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-1120, 7282-1060
Mating Part: 090IIU-6S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10796
QtyPrice
1-5$3.14
6-19$2.98
20-49$2.83
50-99$2.67
100+$2.51
Quantity:  Kit

6-Way Kit
090IIU-6S-1
6-Way Kit
OEM P/N: 6240-5160, 7283-1060
090IIU-6S-1  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-5160, 7283-1060
Mating Part: 090IIU-6P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10797, 90980-12180, 90980-12344, 90980-12349
QtyPrice
1-5$3.03
6-19$2.88
20-49$2.73
50-99$2.58
100+$2.42
Quantity:  Kit

6-Way Kit
090IIU-6S-2
6-Way Kit
OEM P/N: 7283-1061
090IIU-6S-2  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7283-1061
Mating Part: 7382-1177

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10957
QtyPrice
1-5$3.40
6-19$3.23
20-49$3.06
50-99$2.89
100+$2.72
Quantity:  Kit

10-Way Kit
090IIU-10P-2
10-Way Kit
OEM P/N: 6240-1143, 7282-1100
090IIU-10P-2  10-Way Kit
Kit Contents: Housing, 10 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-1143, 7282-1100
Part Name: 10800N9A10M
Mating Part: 090IIU-10S-2

spacer
General
  • Sealing:Unsealed
  • Number of Ways:10
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10800, 90980-11757
QtyPrice
1-5$5.17
6-19$4.91
20-49$4.65
50-99$4.39
100+$4.14
Quantity:  Kit

10-Way Kit
090IIU-10S-2
10-Way Kit
OEM P/N: 6240-5196, 7283-1100
090IIU-10S-2  10-Way Kit
Kit Contents: Housing, 10 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-5196, 7283-1100
Part Name: 10801N9A10F
Mating Part: 090IIU-10P-2

spacer
General
  • Sealing:Unsealed
  • Number of Ways:10
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10801, 90980-12069
QtyPrice
1-5$5.15
6-19$4.89
20-49$4.64
50-99$4.38
100+$4.12
Quantity:  Kit

12-Way Kit
090IIU-12P-1
12-Way Kit
OEM P/N: 6520-1009, 7282-4325
090IIU-12P-1  12-Way Kit
Kit Contents: Housing, 12 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6520-1009, 7282-4325
Part Name: 11692N9A12M
Mating Part: 090IIU-12S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:12
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-11530, 90980-11692
QtyPrice
1-5$5.10
6-19$4.84
20-49$4.59
50-99$4.33
100+$4.08
Quantity:  Kit

12-Way Kit
090IIU-12S-1
12-Way Kit
OEM P/N: 6520-1004, 7283-4325
090IIU-12S-1  12-Way Kit
Kit Contents: Housing, 12 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6520-1004, 7283-4325
Part Name: 11693N9A12F
Mating Part: 090IIU-12P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:12
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-11531, 90980-11693, 90980-12351
QtyPrice
1-5$5.00
6-19$4.75
20-49$4.50
50-99$4.25
100+$4.00
Quantity:  Kit

13-Way Kit
090IIU-13P-1
13-Way Kit
OEM P/N: 6240-1122, 7282-1130, 7282-1530 (w/o clip mount)
090IIU-13P-1  13-Way Kit
Kit Contents: Housing, 13 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-1122, 7282-1130, 7282-1530 (w/o clip mount)
Part Name: 10804N9A13M
Mating Part: 090IIU-13S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:13
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10804
QtyPrice
1-5$5.50
6-19$5.22
20-49$4.95
50-99$4.67
100+$4.40
Quantity:  Kit

13-Way Kit
090IIU-13P-2
13-Way Kit
OEM P/N: 1300-4927 (Natural, in stock), 1300-4928 (Grey), 1300-5539 (Black), 6098-1845 (Blue)
090IIU-13P-2  13-Way Kit
Kit Contents: Housing, 13 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 1300-4927 (Natural, in stock), 1300-4928 (Grey), 1300-5539 (Black), 6098-1845 (Blue)
Part Name: 11694N9A13M-NA
Mating Part: 1300-4682

spacer
General
  • Sealing:Unsealed
  • Number of Ways:13
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-11541, 90980-11694, 90980-11713, 90980-12482, 90980-12531
QtyPrice
1-5$5.70
6-19$5.42
20-49$5.13
50-99$4.85
100+$4.56
Quantity:  Kit

13-Way Kit
090IIU-13S-1
13-Way Kit
OEM P/N: 6240-5175, 7283-1130
090IIU-13S-1  13-Way Kit
Kit Contents: Housing, 13 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-5175, 7283-1130
Part Name: 10805N9A13F
Mating Part: 090IIU-13P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:13
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10805, 90980-12083
QtyPrice
1-5$4.92
6-19$4.67
20-49$4.43
50-99$4.18
100+$3.94
Quantity:  Kit

16-Way Kit
090IIU-16P-1
16-Way Kit
OEM P/N: 7282-1160
090IIU-16P-1  16-Way Kit
Kit Contents: Housing, 16 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7282-1160
Mating Part: 090IIU-16S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:16
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10808
QtyPrice
1-5$6.30
6-19$5.98
20-49$5.67
50-99$5.35
100+$5.04
Quantity:  Kit

16-Way Kit
090IIU-16S-1
16-Way Kit
OEM P/N: 7283-1160, ss by:7283-7967
090IIU-16S-1  16-Way Kit
Kit Contents: Housing, 16 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7283-1160, ss by:7283-7967
Mating Part: 090IIU-16P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:16
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10809
QtyPrice
1-5$6.19
6-19$5.88
20-49$5.57
50-99$5.26
100+$4.95
Quantity:  Kit

16-Way Kit
090IIU-16S-2
16-Way Kit
OEM P/N: 6240-5088
090IIU-16S-2  16-Way Kit
Kit Contents: Housing, 16 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-5088
Part Name: TS090AY-16F
Mating Part: 6240-1158

spacer
General
  • Sealing:Unsealed
  • Number of Ways:16
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10848, 90980-11806
QtyPrice
1-5$5.08
6-19$4.83
20-49$4.57
50-99$4.32
100+$4.06
Quantity:  Kit

18-Way Kit
090IIU-18P
18-Way Kit
OEM P/N: 7282-1180
090IIU-18P  18-Way Kit
Kit Contents: Housing, 18 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7282-1180
Mating Part: 090IIU-18S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:18
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10818, 90980-11759
QtyPrice
1-5$6.15
6-19$5.84
20-49$5.54
50-99$5.23
100+$4.92
Quantity:  Kit

18-Way Kit
090IIU-18S
18-Way Kit
OEM P/N: 7283-1180-90 blue
090IIU-18S  18-Way Kit
Kit Contents: Housing, 18 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7283-1180-90 blue
Mating Part: 090IIU-18P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:18
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10819, 90980-11704
QtyPrice
1-5$6.48
6-19$6.16
20-49$5.83
50-99$5.51
100+$5.18
Quantity:  Kit

20-Way Kit
090IIU-20P-1
20-Way Kit
OEM P/N: 7282-1200
090IIU-20P-1  20-Way Kit
Kit Contents: Housing, 20 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7282-1200
Mating Part: 090IIU-20S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:20
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10820
QtyPrice
1-5$5.95
6-19$5.65
20-49$5.36
50-99$5.06
100+$4.76
Quantity:  Kit

20-Way Kit
090IIU-20P-2
20-Way Kit
OEM P/N: 6240-1035 Natural
6240-1065 Blue (IN STOCK)
090IIU-20P-2  20-Way Kit
Kit Contents: Housing, 20 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-1035 Natural
6240-1065 Blue (IN STOCK)
Part Name: TS090AY20M
Mating Part: 090IIU-20S-2

spacer
General
  • Sealing:Unsealed
  • Number of Ways:20
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10810, 90980-11440
Price: $7.79
Quantity:  Kit

20-Way Kit
090IIU-20S-1
20-Way Kit
OEM P/N: 7283-1200
090IIU-20S-1  20-Way Kit
Kit Contents: Housing, 20 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 7283-1200
Mating Part: 090IIU-20P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:20
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10821
QtyPrice
1-5$6.25
6-19$5.94
20-49$5.62
50-99$5.31
100+$5.00
Quantity:  Kit

20-Way Kit
090IIU-20S-2
20-Way Kit
OEM P/N: 6240-5134 Natural (IN STOCK)
6240-5139 Blue
090IIU-20S-2  20-Way Kit
Kit Contents: Housing, 20 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6240-5134 Natural (IN STOCK)
6240-5139 Blue
Part Name: TS090AY20F-4S
Mating Part: 090IIU-20P-2

spacer
General
  • Sealing:Unsealed
  • Number of Ways:20
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:3
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
spacer
  • Toyota 90980-10811, 90980-11441
QtyPrice
1-5$5.76
6-19$5.47
20-49$5.18
50-99$4.90
100+$4.61
Quantity:  Kit

090II Unsealed Series Pin Contact
090IIU-PIN
090II Unsealed Series Pin Contact
090IIU-PIN  090II Unsealed Series Pin Contact

Mfr: Sumitomo, Yazaki
Series: TS 090 Unsealed, TS 050+090 Hybrid, 090II Unsealed Series, 090II+187 Hybrid Unsealed, 090II+312 Hybrid Unsealed

Wire SizePlatingSumitomoYazaki
-.22-.35 mm2 (24-22 AWG)Tin8230-4742-
-Gold--
090IIU-PIN1.3-.5 mm2 (22-20 AWG)Tin8230-44927114-4020
-Gold8100-13417114-4052-08
090IIU-PIN2.5-1.25 mm2 (20-16 AWG)Tin8230-45027114-4021
-Gold8100-13427114-4053-08
090IIU-PIN32.0 mm2 (14 AWG)Tin8230-45127114-4022
-Gold--
Available stock: Aftermarket OEM

spacer
General
  • Sealing:Unsealed
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
spacer
  • Delphi/Aptiv 13627112
  • KET ST741101-3, ST740672-3, ST740673-3, ST740674-3
  • KUM MT091-61080, MT091-83180
  • Terminal used in Toyota 82998-12330, 82998-12350 (Gold plated) repair wire
QtyPrice
1-49$0.16
50-99$0.15
100-249$0.14
250-499$0.13
500-999$0.12
1000+$0.11
Quantity:  Ea

090II Unsealed Series Socket Contact
090IIU-SKT
090II Unsealed Series Socket Contact
090IIU-SKT  090II Unsealed Series Socket Contact

Mfr: Sumitomo, Yazaki
Series: TS 090 Unsealed, TS 050+090 Hybrid, 090II Unsealed Series, 090II+187 Hybrid Unsealed, 090II+312 Hybrid Unsealed

Wire SizePlatingSumitomoYazaki
-.22-.35 mm2 (24-22 AWG)Tin8240-0029-
-Gold--
090IIU-SKT1.3-.5 mm2 (22-20 AWG)Tin8240-48827116-4020
-Gold8100-13467116-4052-08
090IIU-SKT2.5-1.25 mm2 (20-16 AWG)Tin8240-48927116-4021
-Gold8100-13477116-4053-08
090IIU-SKT32.0 mm2 (14 AWG)Tin8240-49427116-4022
-Gold--
Available stock: Aftermarket OEM

spacer
General
  • Sealing:Unsealed
  • Contact Size:2.3mm (.090)
  • Wire Size:0.50 - 2.00 mm2
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
spacer
  • Delphi/Aptiv 12110740, 12129960, 12129961
  • KET ST731100-3, ST730675-3, ST730676-3, ST730677-3
  • KUM MT095-83080, MT095-83180, MT095-83280
  • Terminal used in Mopar 68080556AA (18 &14 awg Tin) terminal repair kit
  • Terminal used in Toyota 82998-12340, 82998-12360 (Gold plated) repair wire
QtyPrice
1-49$0.16
50-99$0.15
100-249$0.14
250-499$0.13
500-999$0.12
1000-2499$0.11
2500-4999$0.10
5000+$0.09
Quantity:  Ea

Rennsteig PEW 12 Die Set for Sumitomo TS090, Yazaki 090II Unsealed Socket Terminals
TOOL-CDIE55
Rennsteig PEW 12 Die Set for Sumitomo TS090, Yazaki 090II Unsealed Socket Terminals
OEM P/N: 624 1619 3 01 RT
TOOL-CDIE55  Rennsteig PEW 12 Die Set for Sumitomo TS090, Yazaki 090II Unsealed Socket Terminals
Kit Contents: Crimp die set, locator

OEM P/N: 624 1619 3 01 RT

Compatibility
P/NWire SizePlatingSumitomo P/NYazaki P/N
✗-.22-.35 mm2 (24-22 AWG)Tin8240-0029-
Gold--
✓090IIU-SKT1.3-.5 mm2 (22-20 AWG)Tin8240-48827116-4020
Gold8100-13467116-4052-08
✓090IIU-SKT2.5-1.25 mm2 (20-16 AWG)Tin8240-48927116-4021
Gold8100-13477116-4053-08
✗090IIU-SKT32.0 mm2 (14 AWG)Tin8240-49427116-4022
Gold--
NOTE: For 20 AWG wire only

spacer
spacer
spacer
Price: $335.25
Quantity:  Ea


Facebook link spacer Instagram link spacer LinkedIn link spacer Twitter link spacer Twitter link
Privacy Notice | Terms and Conditions | Site Map
© 2009-2024 Corsa Technic, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
R6A1
R7A4
R7A3
R7A2
