Kompakt 1.1
KOM1.1M-4S
4-Way Kit, Code 1
Kit Contents: Housing, 4 socket contacts for 20-18 AWG wire, 4 seals
Mfr: OEM Bosch
Series: Kompakt 1.1
OEM P/N: 1 928 403 736 w/standard seal (IN STOCK)
1 928 405 086 w/standard seal, for oxygen sensor application
1 928 404 658 w/special seal
Code: 1
Mating Part: KOM1-4P-1
Kit Contents: Housing, 4 socket contacts for 20-18 AWG wire, 4 seals
Mfr: OEM Bosch
Series: Kompakt 1.1
OEM P/N: 1 928 403 736 w/standard seal (IN STOCK)
1 928 405 086 w/standard seal, for oxygen sensor application
1 928 404 658 w/special seal
Code: 1
Mating Part: KOM1-4P-1
General
- Sealing:Single Wire Sealed
- Number of Ways:4
- Contact Size:2.8mm (.110)
- Wire Size:0.35 - 2.50 mm2
- Number of Rows:1
- Pitch:5.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:PA66+GF
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:No
- CPA:No
Electrical
- Current Rating[1]:12A
- Voltage Rating:40V
Environmental
- Temp Range[2]:-40 - 150 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Mopar 68528071AA repair kit connector (w/std seal)
BDK-SKT
Bosch Kompakt BDK 2.8 Socket Contact
Mfr: Bosch
Series: Kompakt 1.1, Kompakt 4
Mfr: Bosch
Series: Kompakt 1.1, Kompakt 4
| Wire Size | Plating | Part Number | |
|---|---|---|---|
| BDK-SKT1 | .35 mm2 (22 AWG) | Tin | 1 928 499 396 |
| - | Silver | 1 928 499 395 | |
| - | Gold | 1 928 499 397 | |
| BDK-SKT2 | 0.5-1.0 mm2 (20-18 AWG) | Tin | 1 928 498 056 |
| - | Silver | 1 928 498 058 | |
| - | Gold | 1 928 498 054 | |
| BDK-SKT3 | 1.5-2.5 mm2 (16-14 AWG) | Tin | 1 928 498 057 |
| - | Silver | 1 928 498 059 | |
| - | Gold | 1 928 498 055 | |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Single Wire Sealed
- Contact Size:2.8mm (.110)
- Wire Size:0.35 - 2.50 mm2
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
Electrical
- Current Rating[1]:17A
- Voltage Rating:40V
Environmental
- Temp Range[2]:-40 - 150 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
BDK-SL
Bosch Kompakt BDK 2.8 Seal
Mfr: Bosch
Series: Kompakt 1.1, Kompakt 4
Mfr: Bosch
Series: Kompakt 1.1, Kompakt 4
| Wire Insulation Dia. | Color | Part Number | |
|---|---|---|---|
| BDK-SL1 | 1.2-2.1 mm (.047-.083 in) | Blue | 1 928 300 599 |
| BDK-SL2 | 2.2-3.0 mm (.086-.118 in) | White | 1 928 300 600 |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Single Wire Sealed
- Contact Size:2.8mm (.110)
- Wire Size:0.35 - 2.50 mm2
Mechanical
- Seal Material:Silicone Rubber
Environmental
- Temp Range[2]:-40 - 150 °C
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For detailed characteristics, see applicable product documents.
TOOL-IRT19
BDK 2.8, MCP 2.8 Removal Tool
OEM P/N: 680-24006
OEM P/N: 680-24006
For 2.8 mm Bosch BDK/BSK 2.8; TYCO MCP 2.8 contacts
Comparable with:
MAN 80.99606-0573
VOLVO 888 900 01
Ford 11 15 051
Bosch 1 928 498 167
SPX / Kent Moore J-38125-561
TE Connectivity 2-1579007-9
Walter Schröder 13 43 12
Jaguar / Land Rover JLR-418-656
Comparable with:
MAN 80.99606-0573
VOLVO 888 900 01
Ford 11 15 051
Bosch 1 928 498 167
SPX / Kent Moore J-38125-561
TE Connectivity 2-1579007-9
Walter Schröder 13 43 12
Jaguar / Land Rover JLR-418-656
TOOL-CDIE75
Rennsteig PEW 12 Die Set for Bosch BDK/BSK 2.8 terminals
Kit Contents: Crimp die set, locator
OEM P/N: 624 1615 3 012 RT
Kit Contents: Crimp die set, locator
OEM P/N: 624 1615 3 012 RT
| Compatibility | ||||
|---|---|---|---|---|
| P/N | Wire Size | Plating | Part Number | |
| ✗ | BDK-SKT1 | .35 mm2 (22 AWG) | Tin | 1 928 499 396 |
| Silver | 1 928 499 395 | |||
| Gold | 1 928 499 397 | |||
| ✓ | BDK-SKT2 | 0.5-1.0 mm2 (20-18 AWG) | Tin | 1 928 498 056 |
| Silver | 1 928 498 058 | |||
| Gold | 1 928 498 054 | |||
| ✗ | BDK-SKT3 | 1.5-2.5 mm2 (16-14 AWG) | Tin | 1 928 498 057 |
| Silver | 1 928 498 059 | |||
| Gold | 1 928 498 055 | |||
| ✓ | BSK- | 0.5-1.0 mm2 (20-18 AWG) | Tin | 1 928 498 060 |
| Gold | 1 928 498 062 | |||
| ✗ | BSK- | 1.5-2.5 mm2 (16-14 AWG) | Tin | 1 928 498 061 |
| Gold | 1 928 498 063 | |||
TOOL-CDIE76
Rennsteig PEW 12 Die Set for Bosch BDK/BSK 2.8, BMK 0.6 terminals
Kit Contents: Crimp die set
OEM P/N: 624 1039 3 0 RT
Kit Contents: Crimp die set
OEM P/N: 624 1039 3 0 RT
| Compatibility | ||||
|---|---|---|---|---|
| P/N | Wire Size | Plating | Part Number | |
| ✗ | BDK-SKT1 | .35 mm2 (22 AWG) | Tin | 1 928 499 396 |
| Silver | 1 928 499 395 | |||
| Gold | 1 928 499 397 | |||
| ✗ | BDK-SKT2 | 0.5-1.0 mm2 (20-18 AWG) | Tin | 1 928 498 056 |
| Silver | 1 928 498 058 | |||
| Gold | 1 928 498 054 | |||
| ✓ | BDK-SKT3 | 1.5-2.5 mm2 (16-14 AWG) | Tin | 1 928 498 057 |
| Silver | 1 928 498 059 | |||
| Gold | 1 928 498 055 | |||
| ✗ | BSK- | 0.5-1.0 mm2 (20-18 AWG) | Tin | 1 928 498 060 |
| Gold | 1 928 498 062 | |||
| ✓ | BSK- | 1.5-2.5 mm2 (16-14 AWG) | Tin | 1 928 498 061 |
| Gold | 1 928 498 063 | |||
| ✓ | BMK- (CAN) | 0.35-0.5 mm2 (22-20 AWG) NOTE: .5 mm2 only | Tin | 1 928 498 004 |
| Gold | 1 928 498 005 | |||
| ✓ | BMK- | 0.35-0.5 mm2 (22-20 AWG) NOTE: .5 mm2 only | Tin | 1 928 498 013, ss: 1 928 498 000 |
| Gold | 1 928 498 015, ss: 1 928 498 002 | |||
| ✓ | BMK- | 0.5-0.75 mm2 (20-18 AWG) | Tin | 1 928 498 014, ss: 1 928 498 001 |
| Gold | 1 928 498 016, ss: 1 928 498 003 | |||
