Molex
MCMC-PG064
CMC 0.64mm Plug
Mfr: OEM Molex
Series: CMC Series
OEM P/N: 64325-1010
Mfr: OEM Molex
Series: CMC Series
OEM P/N: 64325-1010
General
- Sealing:Matte Sealed
Mechanical
Environmental
- Temp Range[2]:-40 - 125 °C
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For detailed characteristics, see applicable product documents.
MX150-12P-A
12-Way Kit
Kit Contents: Housing, 12 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-1201 (superseded by 33482-6201)
Keying: A
Mating Part: MX150-12S-A
Kit Contents: Housing, 12 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-1201 (superseded by 33482-6201)
Keying: A
Mating Part: MX150-12S-A
General
- Sealing:Matte Sealed
- Number of Ways:12
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72488-07BK
- Mopar 68490386AA repair kit connector
MX150-12P-B
12-Way Kit
Kit Contents: Housing, 12 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-1202 (ss by: 33482-6202)
Keying: B
Mating Part: 33472-1202, 33472-1207, 33472-1302, 33472-1307
Kit Contents: Housing, 12 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-1202 (ss by: 33482-6202)
Keying: B
Mating Part: 33472-1202, 33472-1207, 33472-1302, 33472-1307
General
- Sealing:Matte Sealed
- Number of Ways:12
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-12S-A
12-Way Kit
Kit Contents: Housing, 12 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-1201
Keying: A
Mating Part: MX150-12P-A
Kit Contents: Housing, 12 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-1201
Keying: A
Mating Part: MX150-12P-A
General
- Sealing:Matte Sealed
- Number of Ways:12
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford AU2Z-14S411-AMA, WPT-1125 (Clip-slot body, Silver plated terminals) pigtail connector
- Harley Davidson 72487-07BK
- Nissan/Bosch J-48817-1120 pigtail connector
- Nissan service part 24008-9DK3A connector
MX150-16P-A
16-Way Kit
Kit Contents: Housing, 16 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-8601 (supersedes: 33482-1601)
Keying: A
Mating Part: MX150-16S-A
Kit Contents: Housing, 16 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-8601 (supersedes: 33482-1601)
Keying: A
Mating Part: MX150-16S-A
General
- Sealing:Matte Sealed
- Number of Ways:16
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72167-07BK
MX150-16S-A
16-Way Kit
Kit Contents: Housing, 16 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-1601
Keying: A
Mating Part: MX150-16P-A
Kit Contents: Housing, 16 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-1601
Keying: A
Mating Part: MX150-16P-A
General
- Sealing:Matte Sealed
- Number of Ways:16
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford CU2Z-14S411-ADA, WPT-1279 (Silver plated terminals) pigtail connector
- Ford 4L3T-14A464-WA
- Harley Davidson 72166-07BK
MX150-20P-A
20-Way Kit
Kit Contents: Housing, 20 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-2001 (ss by: 33482-2101)
Keying: A
Mating Part: MX150-20S-A
Kit Contents: Housing, 20 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-2001 (ss by: 33482-2101)
Keying: A
Mating Part: MX150-20S-A
General
- Sealing:Matte Sealed
- Number of Ways:20
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford 7U2Z-14S411-HA, WPT-890 (Silver plated terminals) pigtail connector
MX150-20P-B
20-Way Kit
Kit Contents: Housing, 20 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-2102 (ss: 33482-2002)
Keying: B
Mating Part: MX150-20S-B
Kit Contents: Housing, 20 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-2102 (ss: 33482-2002)
Keying: B
Mating Part: MX150-20S-B
General
- Sealing:Matte Sealed
- Number of Ways:20
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-20S-A
20-Way Kit
Kit Contents: Housing, 20 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-2001
Keying: A
Mating Part: MX150-20P-A
Kit Contents: Housing, 20 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-2001
Keying: A
Mating Part: MX150-20P-A
General
- Sealing:Matte Sealed
- Number of Ways:20
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford 7U2Z-14S411-GA, WPT-889 (Silver plated terminals) pigtail connector
- Ford 6L3T-14A464-AA
- Harley Davidson 72500-07BK
MX150-20S-B
20-Way Kit
Kit Contents: Housing, 20 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-2002
Keying: B
Mating Part: MX150-20P-B
Kit Contents: Housing, 20 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-2002
Keying: B
Mating Part: MX150-20P-B
General
- Sealing:Matte Sealed
- Number of Ways:20
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-2S-1A
2-Way Kit
Kit Contents: Housing, 2 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0201
Keying: A
Mating Part: 33481-0201
Kit Contents: Housing, 2 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0201
Keying: A
Mating Part: 33481-0201
General
- Sealing:Matte Sealed
- Number of Ways:2
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-3P-1A
3-Way Kit
Kit Contents: Housing, 3 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33481-0301 (superseded by: 33481-3301)
Keying: A
Mating Part: MX150-3S-1A
Kit Contents: Housing, 3 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33481-0301 (superseded by: 33481-3301)
Keying: A
Mating Part: MX150-3S-1A
General
- Sealing:Matte Sealed
- Number of Ways:3
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford AU2Z-14S411-ASA, WPT-1180 (Silver plated terminals) pigtail connector
- Harley Davidson 72511-07BK
- Mopar 68500860AA repair kit connector
MX150-3P-1C
3-Way Kit
Kit Contents: Housing, 3 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33481-0303
Keying: C
Mating Part: MX150-3S-1C
Kit Contents: Housing, 3 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33481-0303
Keying: C
Mating Part: MX150-3S-1C
General
- Sealing:Matte Sealed
- Number of Ways:3
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72541-07BN
MX150-3S-1A
3-Way Kit
Kit Contents: Housing, 3 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0301 (superseded by: 33471-3301)
Keying: A
Mating Part: MX150-3P-1A
Kit Contents: Housing, 3 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0301 (superseded by: 33471-3301)
Keying: A
Mating Part: MX150-3P-1A
General
- Sealing:Matte Sealed
- Number of Ways:3
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72512-07BK
- Mopar 68358151AA repair kit connector
MX150-3S-1C
3-Way Kit
Kit Contents: Housing, 3 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0303 (superseded by: 33471-3303)
Keying: C
Mating Part: MX150-3P-1C
Kit Contents: Housing, 3 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0303 (superseded by: 33471-3303)
Keying: C
Mating Part: MX150-3P-1C
General
- Sealing:Matte Sealed
- Number of Ways:3
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72542-07BN
MX150-4P-1A
4-Way Kit
Kit Contents: Housing, 4 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33481-4401, ss: 33481-0401
Keying: A
Mating Part: MX150-4S-1A
Kit Contents: Housing, 4 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33481-4401, ss: 33481-0401
Keying: A
Mating Part: MX150-4S-1A
General
- Sealing:Matte Sealed
- Number of Ways:4
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-4S-1A
4-Way Kit
Kit Contents: Housing, 4 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0401
Keying: A
Mating Part: MX150-4P-1A
Kit Contents: Housing, 4 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33471-0401
Keying: A
Mating Part: MX150-4P-1A
General
- Sealing:Matte Sealed
- Number of Ways:4
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:1
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford 8U2Z-14S411-TA, WPT-925 (Silver plated terminals) pigtail connector
- Mopar 68358152AA repair kit connector
MX150-4S-2A
4-Way 2-by-2 Kit
Kit Contents: Housing, 4 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0401 (superseded by: 33472-4001)
Keying: A
Mating Part: 33482-0401
Kit Contents: Housing, 4 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0401 (superseded by: 33472-4001)
Keying: A
Mating Part: 33482-0401
General
- Sealing:Matte Sealed
- Number of Ways:4
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford BU2Z-14S411-TA, WPT-1171 (Silver plated terminals) pigtail connector
- Harley Davidson 72177-07BK
- Mopar 68040492AB repair kit connector
MX150-4S-2B
4-Way 2-by-2 Kit
Kit Contents: Housing, 4 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0402 (superseded by: 33472-4002)
Keying: B
Mating Part: 33482-0402
Kit Contents: Housing, 4 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0402 (superseded by: 33472-4002)
Keying: B
Mating Part: 33482-0402
General
- Sealing:Matte Sealed
- Number of Ways:4
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72444-07GY
MX150-6P-2A
6-Way Kit
Kit Contents: Housing, 6 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-3601, supersedes 33482-0601
Keying: A
Mating Part: MX150-6S-2A
Kit Contents: Housing, 6 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-3601, supersedes 33482-0601
Keying: A
Mating Part: MX150-6S-2A
General
- Sealing:Matte Sealed
- Number of Ways:6
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford 5W7T-14A624-EB
- Harley Davidson 72188-07BK
MX150-6P-2C
6-Way Kit
Kit Contents: Housing, 6 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-3628 Gray, Active (IN STOCK)
33482-3603 Brown, End of Life
33482-0603 Brown, Obsolete
Keying: C
Mating Part: MX150-6S-2C
Kit Contents: Housing, 6 pin contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-3628 Gray, Active (IN STOCK)
33482-3603 Brown, End of Life
33482-0603 Brown, Obsolete
Keying: C
Mating Part: MX150-6S-2C
General
- Sealing:Matte Sealed
- Number of Ways:6
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-6S-2A
6-Way Kit
Kit Contents: Housing, 6 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0601
Keying: A
Mating Part: MX150-6P-2A
Kit Contents: Housing, 6 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0601
Keying: A
Mating Part: MX150-6P-2A
General
- Sealing:Matte Sealed
- Number of Ways:6
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford 3U2Z-14S411-FEAB, WPT-971 (Clip-slot body, Silver plated terminals) pigtail connector
- Harley Davidson 72414-07BK
- Mopar 68225123AA repair kit connector
MX150-6S-2C
6-Way Kit
Kit Contents: Housing, 6 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0603 (superseded by 33472-0669)
Keying: C
Mating Part: MX150-6P-2C
Kit Contents: Housing, 6 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-0603 (superseded by 33472-0669)
Keying: C
Mating Part: MX150-6P-2C
General
- Sealing:Matte Sealed
- Number of Ways:6
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
MX150-8S-A
8-Way Kit
Kit Contents: Housing, 8 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-4801 (supersedes 33472-0801)
Keying: A
Mating Part: 33482-0801
Kit Contents: Housing, 8 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-4801 (supersedes 33472-0801)
Keying: A
Mating Part: 33482-0801
General
- Sealing:Matte Sealed
- Number of Ways:8
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72479-07BK
- Ford CU2Z-14S411-ALA, WPT-1276 (Silver plated terminals) pigtail connector
- Ford CU2Z-14S411-AZA, WPT-1310 (Silver plated terminals) pigtail connector
MX150-8S-B
8-Way Kit
Kit Contents: Housing, 8 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-4802 (supersedes 33472-0802)
Keying: B
Mating Part: 33482-0802
Kit Contents: Housing, 8 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33472-4802 (supersedes 33472-0802)
Keying: B
Mating Part: 33482-0802
General
- Sealing:Matte Sealed
- Number of Ways:8
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72469-07GY
MX150-8S-D
8-Way Kit
Kit Contents: Housing, 8 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: Green: 33472-4880 (SS: 33472-0804)
Black: 33472-4805 (SS: 33472-0805)
Gray: 33472-4882 (SS: 33472-0882, IN STOCK)
Keying: D
Mating Part: 33482-0804
Kit Contents: Housing, 8 socket contacts
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: Green: 33472-4880 (SS: 33472-0804)
Black: 33472-4805 (SS: 33472-0805)
Gray: 33472-4882 (SS: 33472-0882, IN STOCK)
Keying: D
Mating Part: 33482-0804
General
- Sealing:Matte Sealed
- Number of Ways:8
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
- Number of Rows:2
- Pitch:3.5mm
- Row Spacing:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Housing Material:SPS/PA+GF20
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes, connector option
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
- Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Ford DU2Z-14S411-ACA, WPT-1358 (Black body, Silver plated terminals) pigtail connector
MX150-PG
MX150 Sealed Series Plug
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 34345-0001
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 34345-0001
- Harley Davidson 72473-07
MX150-PIN
MX150 Sealed Series Pin Contact
Mfr: Molex
Series: MX150 Sealed Series
Mfr: Molex
Series: MX150 Sealed Series
| Wire Size | Plating | Part Number | |
|---|---|---|---|
| MX150-PIN1 | .3 mm2 (22 AWG) | Tin | 33000-1003 |
| - | Gold | 33011-0006 | |
| MX150-PIN2 | .5-1.25 mm2 (20-16 AWG) | Tin | 33000-1002 |
| - | Gold | 33011-0004 | |
| MX150-PIN3 | 2.0 mm2 (14 AWG) | Tin | 33000-1001 |
| - | Gold | 33011-0002 | |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Matte Sealed
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72169-07
- Terminal used in Mopar 68364268AA (18 &14 awg Tin) terminal repair kit
MX150-SKT
MX150 Sealed Series Socket Contact
Mfr: Molex
Series: MX150 Sealed Series, also used in TE GET.64 Interconnection System
Mfr: Molex
Series: MX150 Sealed Series, also used in TE GET.64 Interconnection System
| Wire Size | Plating | Part Number | |
|---|---|---|---|
| MX150-SKT1 | .3 mm2 (22 AWG) | Tin | 33012-3003 |
| - | Gold | 33001-3005 | |
| MX150-SKT2 | .5-.85 mm2 (20-18 AWG) | Tin | 33012-3002 |
| - | Gold | 33001-3004 | |
| MX150-SKT3 | 1.25-2.0 mm2 (16-14 AWG) | Tin | 33012-3001 |
| - | Gold | 33001-3003 | |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Matte Sealed
- Contact Size:1.5mm (.060)
- Wire Size:0.35 - 2.00 mm2
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
Electrical
- Current Rating[1]:22A
Environmental
- Temp Range[2]:-40 - 150 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Harley Davidson 72168-07
- Terminal used in Mopar 68364272AA (14 awg Tin) terminal repair kit
- Nissan/Bosch J-48817-269 repair wire terminal
TOOL-IRT5
MX-150 Terminal Removal Tool
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 63813-1500
Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 63813-1500
1.50mm (.059") service tool
© 2009-2024 Corsa Technic, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
